Fixed Boom Side Brush Cutter Attachment 12-25 gpm

Price: $8,300.00
free ground shipping
(No reviews yet) Write a Review
In Stock
990.00 LBS

Calculate Shipping Cost

The Spartan Fixed Boom Side Brush Cutter Attachment is a great implement to add to your arsenal. It is designed for cutting banks, fence lines, and right of ways. It also is an excellent choice for clearing pond banks and cutting trails. This cutter has a significant reach advantage over our typical brush cutters. Equipped with a 115-degree range of motion, 90° degrees vertical and negative 25 degrees from horizontal. With a 90° side reach of 72” horizontally and a vertical reach of 16 feet or more (depending on the reach height of your machine), it makes clearing unwanted tree limbs less of a chore. It is equipped with two blades (5/8 in Thick X 5 in Long X 5.5 in Wide) and is powered by a high torque piston type hydraulic motor with a 4000 psi relief valve coupled to a right angle reduction gear-box. A range of hydraulic flow of 12-25 gpm is required. This unit comes with Two Hoses, 1/2" Flat Face Couplers, In-Cab Universal Remote Electrical Attachment Control Kit, two batteries, and a 12 volt in-cab battery charging adapter. 1 year warranty. Skid Steer or Compact Track Loader recommended 65 hp and higher. Our attachments are USA made with the highest quality steel and components.

*Wear Items, Hoses, and Couplers are not covered under warranty

1 Year Warranty (does not cover wear items or hoses & couplers)
990 lbs
Hydraulic Flow Required:
12-25 gpm
Cutting Blades (AR400 Grade Steel):
2 Blades (5/8 in Thick X 6 in Long X 5.5 in Wide)
Material Cutting:
Up to 4 in dia
Deck Width (Overall):
42 in
Deck Thickness:
3/16 in
Cutting Width:
42 in
Height at 90°:
56.5 in
93 in
Forward Reach:
Vertical Reach (Varies by Loader):
254 in
Total Range of Motion (Tilting):
Max Tilt (Up):
Max Tilt (Down):
Piston Motor with RT Angle Reduction Gear Box
If manual required please contact us
