Skid Steer Planer Attachment Model HP400 16" High Flow

Price: $28,350.00
free ground shipping
(No reviews yet) Write a Review
SE100793 | 0
2,150.00 LBS

Calculate Shipping Cost

  • Our Industrial Series High Flow Planers have a hydraulic flow range of 22-44 gpm
  • Planetary drive delivers high torque
  • High rear spoil clearance to prevent recirculation of material
  • Protective shields for hydraulic & electrical components
  • Solid hardened steel wheels with greasable manifold pins and secluded greased zerks
  • (Includes Drum assembly & Deutsch - 14 pin electrical connector with joystick)

  • Exclusive angled spoil guard wheel design prevents wheels from riding up and over millings, this feature provides more force to the cutting action by signifi cantly reducing rolling resistance and allow for maintained control over depth of cut
  • Fully adjustable with electro-hydraulic controls
  • Manual depth and tilt option available on standard flow Cold Planer ONLY
  • Convenient for milling frost heaves, expansion joints, railroad approaches, etc.
  • Optional Water nozzle kit with integral water nozzle ports
  • Optional in-cab control harness for most skid-steer loader models
  • Pick maintenance tool included and stowed with the Cold Planer
  • Convenient ergonomic electro-hydraulic control joystick for depth, tilt and side shift standard
  • Independent self-leveling depth adjustment plates which allow for precise lapping cuts and taper cuts
  • Replaceable steel bushings at pivot locations
  • Efficient piston drive motor
*Wear Items, Hoses, and Couplers are not covered under warranty

Model SP300HP400HP450HP600HP750HP1000
Planing Width 12.0" 16.0" 18.0" 24.0" 30.0" 40.0"
Planing Depth 0-5" 0-5" 0-5" 0-5" 0-5" 0-5"
# of Carbide Picks 37 43 45 57 59 89
Weight 1500 lbs 2150 lbs 2200 lbs 2400 lbs 2600 lbs 3100 lbs
Hydraulic Requirements standard high-flow high-flow
Hydraulic Flow Range 12-22 gpm 22-40 gpm 22-40 gpm
Overall Width 51.94" 64.94" 64.94"
Overall Height 32.15" 34.57" 34.57"
Overall Length 43.86" 50.30" 50.30"
Tilt ±11° ±8° ±8°
Drum Diameter 19.0" 22.0" 22.0"
Sideshift (to right) 0" to 9" -3" to 22" -3" to 22"
Operating Pressure 2500-3000 psi 2500-3000 psi 2500-3000 psi

1 Year Warranty (does not cover wear items or hoses & couplers)
If manual required please contact us
